Perc Mono 132 Half Cell Solar Panels 485w 182mm Cell 10BB Solar Lighting Panels
1PC
MOQ
Negotiable
Price
Perc Mono 132 Half Cell Solar Panels 485w 182mm Cell 10BB Solar Lighting Panels
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Wuhan, China
Brand Name: Rixin
Certification: TUV, CE, ISO9001, ISO14001, OHSAS18000
Model Number: DBG485(P)
High Light:

Mono 132 Half Cell Solar Panels

,

485w Perc Half Cell Solar Panels

,

182mm 10BB Solar Lighting Panels

Payment & Shipping Terms
Packaging Details: 155 PCS/20GP,682pcs/40HQ
Delivery Time: 15 working days
Payment Terms: T/T
Supply Ability: 500MW/year
Specifications
Power: 485W
Dimension: 2094*1134*35mm
Power Tolerance: -0~+5%
Efficiency: 20.4%
Warranty: 25 Years Output Power Gurantee
Cell Type: 132 Cell Half Cut PERC Solar Panel
Weight: 26.3Kgs
Application: Solar Farm/Solar Stations
Junction Box: IP67 Rated
Type: Customized Solar Panel
Solar Panel: Monocrystalline Solar Panel
Product Description

Perc Mono 132 half cells Solar Panels 485w 182mm cell 10BB Solar Lighting Panels




Key Features



1. High cell efficiency with quality silicon materials for long term output stability

2. Strictly quality control ensure the stability and reliability, totally 23 QC procedures
3. Manufactured according to international quality and environment Mangement System(ISO9001, ISO14001)

4. High efficiency crystalline silicon solar cells

5. Anodized aluminum frame improves load resistance capabilities for heavy wind loads

6. standard waterproof junction box

7. High endurance to different weather

8. Good and friendly package with less transportation and storage space



Advantages:





1. Manufactured according to international quality and Environment Management System (ISO9001, ISO14001)

2. High efficiency crystalline silicon solar cells

3. High transmission Iow iron tempered glass, strong mechanical resistance

4. Anti-ageing EVA and excellent anti-climate back sheet

5. Anodized aluminum frame improves load resistance capabilities for heavy wind loads.

6. Standard waterproof junction box

7.High endurance to different weather

8.Good and friendly package with less transportation and storage space













Electrical performance parameters

Perc Mono 132 half cells Solar Panels 485w 182mm cell 10BB Solar Lighting Panels
STC (AM1.5, 1000W/m², cell temperature 25℃)
Model DBG485(P)
Maximum power (Pm/Wp)

485

Maximum power voltage (Vmp/V) 37.82
Maximum power current (Imp/A) 12.83
Open circuit voltage (Voc/V) 45.2
Short circuit current (Isc/A) 13.72
Module efficiency (%) 20.4
Normal operating cell temperature (NOCT) 45±2℃
Temperature coefficient of Voc -0.0.35%/℃
Temperature coefficient of Isc 0.0275%/℃
Temperature coefficient of Pm -0.45%/℃
Power tolerance (W) 0~+5



General performance parameters

Mechanical performance parameters
Module dimension (L*W*H) (mm) 2094*1134*35
Cell dimension(mm) 182mm Mono cells
Module weight (kg) 26.3
Cable cable section-4mm2 length-1000mm
Cell Nos & array 132(2*6*11)
Packing 155pcs/20GP; 682pcs/40HQ
Quality parameters
Module working temperature range (℃) -40~+85
Maximum system voltage (V Dc) 1000
System maximum protection current (A) 15
Maximum wind loads/maximum snow loads (Pa) 2400/5400
Hot-spot resistance 100% hot-spot free









Drawing(mm)


Perc Mono 132 Half Cell Solar Panels 485w 182mm Cell 10BB Solar Lighting Panels 0







Perc Mono 132 Half Cell Solar Panels 485w 182mm Cell 10BB Solar Lighting Panels 1





Quality Warranty
10-year materials&workmanship warranty
25-year linear power warranty

Perc Mono 132 Half Cell Solar Panels 485w 182mm Cell 10BB Solar Lighting Panels 2Perc Mono 132 Half Cell Solar Panels 485w 182mm Cell 10BB Solar Lighting Panels 3



About Rixin:



♦ Founded in 2001 , 500MW solar panel production capacity

♦ Three factories , Wuhan solar panel factory , Huangshi Solar Panel factory , Huangshi Solar Brackets factory
♦ Products are exported to many countries all over the world
♦ Products are certified by TUV(Germany) , CE

♦ Turn-key solar systems are offered , to save the time and money for the clients
♦ Rich experience in overseas construction of solar projects
