395W 400W 405W 410 Watt PERC PV Module High Output Solar Panels
620pcs/HQ
MOQ
Negotiable
Price
395W 400W 405W 410 Watt PERC PV Module High Output Solar Panels
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Wuhan, China
Brand Name: Rixin
Certification: TUV, CE, ISO9001, ISO14001, OHSAS18000
Model Number: SKT410M10
High Light:

410 Watt PERC PV Module

,

405W PERC PV Module

,

395W High Output Solar Panels

Payment & Shipping Terms
Packaging Details: 216pcs/20GP,936pcs/40HQ
Delivery Time: 15 working days
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 3GW/year
Specifications
Power: 410W
Dimension: 1722*1134*30mm
Power Tolerance: -0~+5%
Efficiency: 21%
Life Span: 25 Years
Type: 108 Cell Half Cut PERC Solar Panel
Weight: 20.5Kgs
Back Sheet: Co-excrusion Backsheet
Product Description

            Solar Power Panel 395W 400W 405W 410 Watt Monocrystalline Solar Module Panel

Main Features



1. High transmissivity, low-iron tempered glass

2. Using high efficiency mono solar cells

3. Excellent performance in low-lights environment

4. Hight quality junction box and connector systems

5. 100% inspection, to guarantee the reliability of solar systems

6. Anti LID

7. Anti PID

8. Lower temperature conefficient



Electrical performance parameters

Solar Power Panel 395W 400W 405W 410 Watt Monocrystalline Solar Module Panel
STC (AM1.5, 1000W/m², cell temperature 25℃)
Model SKT410M10
Maximum power (Pm/Wp) 410
Maximum power voltage (Vmp/V) 31.45
Maximum power current (Imp/A) 13.04
Open circuit voltage (Voc/V) 37.32
Short circuit current (Isc/A) 13.95
Module efficiency (%) 21.00
Normal operating cell temperature (NOCT) 45±2℃
Temperature coefficient of Voc -0.0.275%/℃
Temperature coefficient of Isc 0.045%/℃
Temperature coefficient of Pm -0.35%/℃
Power tolerance (W) 0~+4.99



General performance parameters

Mechanical performance parameters
Module dimension (L*W*H) (mm) 1722*1134*30
Cell dimension(mm) Mono crystalline 182 mm
Module weight (kg) 20.5
Cable cable section-4mm2 length-300mm
Cell Nos & array 108(54*2)
Packing 216/20GP, 936pcs/40HQ
Quality parameters
Module working temperature range (℃) -40~+85
Maximum system voltage (V Dc) 1000
System maximum protection current (A) 15
Maximum wind loads/maximum snow loads (Pa) 2400/5400
Hot-spot resistance 100% hot-spot free




Drawing(mm)




395W 400W 405W 410 Watt PERC PV Module High Output Solar Panels 0









Quality Warranty
10-year materials&workmanship warranty
25-year linear power warranty



395W 400W 405W 410 Watt PERC PV Module High Output Solar Panels 1



Management System



ISO 9001 -- Quality Management System



ISO 14001 -- Standard for environmental management system



OHSAS 18001 -- International standard for occupational health and safety accessment system
