amorphous thin film solar panel / 80W
Main features
1. Lower cost, excellent weak light effect.
2. Induce astigmatism/reflected light.
3. Generate electricity even in rainy and cloudy days.
4. Better high temperature performance, the total generating capacity is higher.
5. No raw material limation, can be manufactured in mass, higher VOC.
6. Less degradation, over 20 years' life time.
Performance parameters
| amorphous thin film solar panel / 80W | |||
| Type | RXJP3–ABS80 | ||
|
Electricity Performance
|
Wp Peak Power Output (W) |
80Wp | |
|
Vmp Maximum Power Voltage (V) |
99.2 V | ||
|
Imp Maximum Power Current |
0.81 A | ||
|
Isc Short Circuit Current(A) |
1.0 A | ||
|
Voc Open Circuit Voltage(V) |
132.9V | ||
| Max system voltage | 1000V | ||
|
Mechanical Performance
|
Working Temperature | -40-85℃ | |
| Front cover | 3.2mm thin film solar cell | ||
| Back cover | 4mm float glass | ||
|
Solar panel Temperature Coefficient
|
Power TK(Pm) | -0.21%/℃ | |
| Open Circuit Voltage TK(VOC) | -0.28%/℃ | ||
| Short Circuit Current TK(ISC) | +0.04%/℃ | ||
| Dimension(mm) | 1300*1100*7.8 | ||
| Module weight(kg) | 27KG | ||
