Polycrystalline Custom Solar Panels 50W / 36 Cells / 12V IP65 PV modules
1PC
MOQ
Negotiable
Price
Polycrystalline Custom Solar Panels 50W / 36 Cells / 12V IP65 PV modules
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Wuhan, China
Brand Name: Rixin
Certification: TUV, CE, ISO9001, ISO14001, OHSAS18000
Model Number: MBF50
High Light:

custom size solar cells

,

custom made solar panels

Payment & Shipping Terms
Packaging Details: cartons/wooden cases
Delivery Time: 15 working days
Payment Terms: T/T
Supply Ability: 500MW/year
Specifications
Power: 50W
Dimension: 541*670*35mm
Cells: 36cells
Life Span: 25 Years
Name: Custom Solar Panels
Application: Roof Off Grid Solar System
OEM: SUPPORT
Type: Monocrystalline Silicon Solar Panel
Product Description

Polycrystalline Custom Solar Panels 50W / 36 Cells / 12V IP65 PV modules


Solar panel helps us to take full advantage of solar energy which is clean, inexhautible and pollution-free, and it converts sunlight into electric. In this way, we can help people in remote areas without mains supply and lack of electricity, and light up nights and bring people hope there.




Main Features
1. Over 25-year lifespan.

2. Available for charging 12V/24V battery.

3. Module dimension could be customized.

4. Suitable for solar street light, solar garden light, solar pump etc., on-grid or off-grid system.


Performance parameters



Model MBF50
Dimension (L*W*H) mm 541*670*35
Weight (kg) 4.21
Cell dimension (mm) 156*52
Cell Nos 36 (4*9)
Glass 3.2mm low-iron tempered glass
Frame Anodized aluminum alloy
Mounting holes customized
Junction box protection level IP65
Cable length customized
Connector customized, MC4 compatible
Power tolerance ±5%
Maximum power (Pm/Wp) 50
Maximum power voltage (Vmp/V) 18.5
Maximum power current (Imp/A) 2.70
Open circuit voltage (Voc/V) 22.0
Short circuit current (Isc/A) 2.88


Quality Warranty
10-year materials&workmanship warranty
25-year linear power warranty



Polycrystalline Custom Solar Panels 50W / 36 Cells / 12V IP65 PV modules 0Polycrystalline Custom Solar Panels 50W / 36 Cells / 12V IP65 PV modules 1Polycrystalline Custom Solar Panels 50W / 36 Cells / 12V IP65 PV modules 2Polycrystalline Custom Solar Panels 50W / 36 Cells / 12V IP65 PV modules 3

Rixin Technology is a clean energy company as well as one of the China’s leading crystalline silicon solar power companies, committed to change the world by solar energy.

Formed in 2001, the company is headquartered in Wuhan.It has two manufacturing bases, with area 180000 square meters and fully automatic production lines. Through its rational investment and industrial, Rixin Technology has formed an entire chain including R&D of core technology, manufacturing, integration and service etc.

With core products covering high efficiency Perc mono half-cut bifacial module, BIPV laminated double glass module, Perc mono/poly framed solar panel, solar power system etc, at present, Rixin Technology’s total installed capacity of solar projects exceeds 1GW.

Rixin Technology believes that high efficiency crystalline modules will define the future of PV industry. Rixin Technology specializes in the development of high efficiency crystalline solar technical roadmap and it has become great PV companies in terms of its scale and the leading expertise in China.

We use top-quality solar cells and EVA, TPT, strengthen glass, seal silicone etc. Our experienced staffs work together well to assurance quality under effective ISO system, CE, to assure our quality Our products are exported to Europe, America and Asian countries with safety certificates.

Our value is coordination, innovation, sincerity, service. We will make unremitting efforts to be your great partner on your path of the photovoltaic wealth.
