All Black BIPV Solar Panels Monocrystalline Silicon Solar Panel 6v 540w
100000watt
MOQ
0.21 USD/watt
Price
All Black BIPV Solar Panels Monocrystalline Silicon Solar Panel 6v 540w
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: Rixin
Certification: CE\Rohs\CCC\ISO9001
Model Number: BIPV
High Light:

540w BIPV Solar Panels

,

All Black BIPV Solar Panels

,

540w BIPV Solar MODULE

Payment & Shipping Terms
Packaging Details: Safety standard installation
Delivery Time: 7 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,payapl
Supply Ability: 1000000000watt/week
Specifications
Name: BIPV SOLAR PANEL
Cell Nos & Array: Customized Solar Panel
Feature: Customized Solar Panel
Frame: Anodized Alaminum Alloy
Application: Building
Color: Customized Solar Panel
Size: Customized Solar Panel
Product Description

Rixin BIPV Solar Panels all Black Monocrystalline Silicon Solar Panel 6v 540w

All Black BIPV Solar Panels Monocrystalline Silicon Solar Panel 6v 540w 0

Self-branded

Formed in 2001,has a total of 500 employees. It has two manufacturing bases, with area 180000㎡ and fully automatic production lines.

Industry Experience

Rixin Technology is a clean energy company as well as one of the China’s leading crystalline silicon solar power companies.

Competitive products

High efficiency Perc mono half-cut bifacial module, BIPV laminated double glass module, Perc mono/poly framed solar panel, solar power system etc, at present, Rixin Technology’s total installed capacity of solar projects exceeds 1GW.

Professional Team



Certificate standard

Have IEC61215, IEC61730, CE, ISO9001 ,ISO14001 certificates



All Black BIPV Solar Panels Monocrystalline Silicon Solar Panel 6v 540w 1All Black BIPV Solar Panels Monocrystalline Silicon Solar Panel 6v 540w 2All Black BIPV Solar Panels Monocrystalline Silicon Solar Panel 6v 540w 3All Black BIPV Solar Panels Monocrystalline Silicon Solar Panel 6v 540w 4All Black BIPV Solar Panels Monocrystalline Silicon Solar Panel 6v 540w 5



Mono Bifacial Double Glass Module DDG(P)530-550(k)

Model DDG(P)530(k) DDG(P)535(k) DDG(P)540(k) DDG(P)545(k) DDG(P)550(k)
Maximum power(Pm/Wp) 530 535 540 545 550
Maximum power voltage(Vmp/V) 41.64 41.87 42.09 42.32 42.54
Maximum power current(lmp/V) 12.73 12.78 12.83 12.88 12.93
Open circuit voltage(Voc/V) 49.65 49.78 49.91 50.12 50.34
Short circuit current(Isc/A) 13.48 13.53 13.58 13.63 13.68
Module efficient(%) 20.45 20.64 20.83 21.03 21.22

Test condition:irradiance=(1+0.1BiFi)1000W/㎡,ambient temperature=25℃,AM=1.5



Mechanical performance parameters

Cell Nos & array Mono half-cut cells 144 pcs
Cell size (mm) 182*91
Glass thickness (mm) 2.0
Frame Anodized alaminum alloy
Cable 4m㎡ negetive300mm, positive300mm
Module weight (kg) 32.1
Module dimension (L*W*H)(mm) 2285*1134*35mm
Packing 31pcs/pallet



Quality parameters

Module working temperature range (℃) -40~ +85
Power tolerance(W) 0~+5
Maximum system voltage(V) DC1500
System maximum protection current(A) 25
NOCT(℃) 45±2
Front/rear static loads(Pa) 2400 / 5400
Junction box/Connector Ip68,split / MC4 compatible



Temperaturecoefficient(STC)

Temperature coefficient of Voc -0.3%/℃
Temperature coefficient of Isc +0.06%/℃
Temperature coefficient of Pm -0.39%/℃
Test condition:irradiance=(1+0.1BiFi)1000W/㎡,ambient temperature=25℃,AM=1.5



Quality warranty

12-year material & workmanship warranty

30-year linear power warranty



All Black BIPV Solar Panels Monocrystalline Silicon Solar Panel 6v 540w 6

All Black BIPV Solar Panels Monocrystalline Silicon Solar Panel 6v 540w 7

Rixin Technology is a clean energy company as well as one of the China’s leading crystalline silicon solar power companies, committed to change the world by solar energy.

Formed in 2001, the company is headquartered in Wuhan.It has two manufacturing bases, with area 180000 square meters and fully automatic production lines. Through its rational investment and industrial, Rixin Technology has formed an entire chain including R&D of core technology, manufacturing, integration and service etc.

With core products covering high efficiency Perc mono half-cut bifacial module, BIPV laminated double glass module, Perc mono/poly framed solar panel, solar power system etc, at present, Rixin Technology’s total installed capacity of solar projects exceeds 1GW.

Rixin Technology believes that high efficiency crystalline modules will define the future of PV industry. Rixin Technology specializes in the development of high efficiency crystalline solar technical roadmap and it has become great PV companies in terms of its scale and the leading expertise in China.

We use top-quality solar cells and EVA, TPT, strengthen glass, seal silicone etc. Our experienced staffs work together well to assurance quality under effective ISO system, CE, to assure our quality Our products are exported to Europe, America and Asian countries with safety certificates.

Our value is coordination, innovation, sincerity, service. We will make unremitting efforts to be your great partner on your path of the photovoltaic wealth.



RFQ

Q1 : What about delivery time?

A : Samples:within 7 working days.

Goods : 7-15 working days usually.

Q2 : Can you provide OEM service?

A : Yes,we can.Including customized logo/customized packaging/Graphic customization.

Q3 : Do you test the goods before shipment ?

A : Yes,we have professional QC team to test all the goods before packing.And we will check the packing before shipment.

Q4 : What about the quality warranty?

A : 12-year material & workmanship warranty.

      30-year linear power warranty.

Q5: What is you payment terms?

A : We accept T/T bank transfer,L/C, Paypal, Western union and MonryGram.

Q6 :What is your products’ advantage?

A : First ,we own our brand and we have over 20 years produce experience.We have cooperation projects with governments and well-known companies and have won a good reputation.
