Renewable Energy System Bifacial Solar Panels 182mm 144pcs Monocrystalline Solar Cells
840PCS/HQ
MOQ
Negotiable
Price
Renewable Energy System Bifacial Solar Panels 182mm 144pcs Monocrystalline Solar Cells
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Wuhan, China
Brand Name: Rixin
Certification: TUV, CE, ISO9001, ISO14001, OHSAS18000
Model Number: Renewable Energy System
High Light:

Bifacial Solar Panels

,

Double Sided Solar Panels

Payment & Shipping Terms
Packaging Details: Safety packaging as per your requirements
Delivery Time: 15 working days after order onfirmation
Supply Ability: 3GW per year
Specifications
Mount Directions: Vertical,horizontal
Application: Commercial,Residential, Farm, Power Station
Certification: GB, ISO, TUV, CE
Origin: Wuhan, China
Feature: Bifacial Solar Panel
Warranty: 30 YEARS
Product Description

Renewable Energy System Bifacial Solar Panels 182mm 144pcs Monocrystalline Solar Cells



Renewable Energy System Bifacial Solar Panels 182mm 144pcs Monocrystalline Solar Cells 0Renewable Energy System Bifacial Solar Panels 182mm 144pcs Monocrystalline Solar Cells 1

Mono DDP315-325(K)

Model DDP315(K) DDP320(K) DDP325(K)
Maximum power(Pm/Wp) 315 320 325
Maximum power voltage(Vmp/V) 29.3 29.4 29.5
Maximum power current(lmp/V) 10.75 10.88 11.00
Open circuit voltage(Voc/V) 35.9 36 36.1
Short circuit current(Isc/A) 11.54 11.60 11.66
Module efficient(%) 19.0 19.3 19.6

Test condition:irradiance=(1+0.1BiFi)1000W/㎡,ambient temperature=25℃,AM=1.5



Mechanical performance parameters

Cell Nos & array Mono half-cut cells 108 (6*9*2)
Appearance color Black
Cable 4m㎡ negetive1000mm,positive1000mm
Module weight (kg) 19
Module dimension (L*W*H)(mm) 1600*1036*5mm
Packing 33pcs/pallet
Power optimizer matching form 2 modules equipped with 1 optimizer



Quality parameters

Module working temperature range (℃) -40~ +85
Power tolerance(W) 0~+5
Maximum system voltage(V) DC1500
System maximum protection current(A) 20
NOCT(℃) 45±2
Front/rear static loads(Pa) 2400 /2400
Junction box/Connector Ip68,split / MC4 compatible



Temperaturecoefficient(STC)

Temperature coefficient of Voc -0.3%/℃
Temperature coefficient of Isc +0.06%/℃
Temperature coefficient of Pm -0.39%/℃
Test condition:irradiance=(1+0.1BiFi)1000W/㎡,ambient temperature=25℃,AM=1.5



Quality warranty

12-year material & workmanship warranty

30-year linear power warranty




Datasheet of Renewable Energy System

SPECIFICATION
Description Ground mounting Roof bracket Carport Agricultural bracket Single column stand
Field status open area
Max wind load ≤60m/s / <46m/s <46m/s ≤46m/s
Height Depending
Snow load Depending
Tilt Angle 0~45° As per requirement 0~45° 0~30° 0~45°
Mount Directions Vertical,horizontal
Standard GB/T2518-2008 & GB/T10125-2012
Body material S550GD+Z350
Bolt material SUS304
Base material Q235/Cement
Surface treatment Galvanized mg-al
Warranty 10 Years



Why it's worth to choose Rixin system for photovoltaic farms?



Up to 25 years' product warranty on anti-corrosion coating

High durability

Extremely high corrosion resistance

No electrocorrosion effect

Safety and standards confirmed by certificates







Renewable Energy System Bifacial Solar Panels 182mm 144pcs Monocrystalline Solar Cells 2
