80 W Amorphous Cilicon BIPV Solar Panels Thin Film Modules ISO14001 Certification
100PCS
MOQ
Negotiable
Price
80 W Amorphous Cilicon BIPV Solar Panels Thin Film Modules ISO14001 Certification
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Wuhan, China
Brand Name: Rixin
Certification: TUV, CE, ISO9001, ISO14001, OHSAS18000
Model Number: RXJP3-ABS80
High Light:

bipv solar tiles

,

building integrated photovoltaics bipv

Payment & Shipping Terms
Packaging Details: wooden case
Delivery Time: 15 working days
Payment Terms: T/T, L/C
Supply Ability: 3GW/YEAR
Specifications
Power: 80W
Dimension: 1300mm*1100mm*7.8mm
Wp Peak Power Output (W): 80Wp
Module Weight(kg): 27KG
Working Temperature: -40-85℃
Certification: TUV, CE, ISO9001, ISO14001, OHSAS18000
Product Description



80W Amorphous cilicon solar panel Thin Film BIPV solar Modules



Main features

1. Lower cost, excellent weak light effect.

2. Induce astigmatism/reflected light.

3. Generate electricity even in rainy and cloudy days.

4. Better high temperature performance, the total generating capacity is higher.

5. No raw material limation, can be manufactured in mass, higher VOC.

6. Less degradation, over 20 years' life time.


Performance parameters

80W Amorphous cilicon solar panel Thin Film BIPV solar Modules
Type RXJP3–ABS80

Electricity

Performance



Wp

Peak Power Output (W)

80Wp

Vmp

Maximum Power Voltage (V)

99.2 V

Imp

Maximum Power Current

0.81 A

Isc

Short Circuit Current(A)

1.0 A

Voc

Open Circuit Voltage(V)

132.9V
Max system voltage 1000V

Mechanical

Performance



Working Temperature -40-85℃
Front cover 3.2mm thin film solar cell
Back cover 4mm float glass

Solar panel

Temperature

Coefficient



Power TK(Pm) -0.21%/℃
Open Circuit Voltage TK(VOC) -0.28%/℃
Short Circuit Current TK(ISC) +0.04%/℃
Dimension(mm) 1300*1100*7.8
Module weight(kg) 27KG

80 W Amorphous Cilicon BIPV Solar Panels Thin Film Modules ISO14001 Certification 080 W Amorphous Cilicon BIPV Solar Panels Thin Film Modules ISO14001 Certification 1
