Rixin Polycrystalline PV Module dual glass solar panel / 330W / 72cells / 24V
1PC
MOQ
Negotiable
Price
Rixin Polycrystalline PV Module dual glass solar panel / 330W / 72cells / 24V
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Wuhan, China
Brand Name: Rixin
Certification: TUV, CE, ISO9001, ISO14001, OHSAS18000
Model Number: MDG330(W)
High Light:

polycrystalline solar module

,

polycrystalline silicon solar panels

Payment & Shipping Terms
Packaging Details: 30pcs/carton, 22cartons/40HQ, 660pcs/40HQ
Delivery Time: 15 working days
Payment Terms: T/T
Supply Ability: 500MW/year
Specifications
Power: 330W
Dimension: 1968*992*6mm
Efficiency: 16.90%
Life Span: 30 Years
Junction Box: IP 67
Product Name: Mini Pv Solar Module
Cable: 4mm2
Oem: Acceptable
Product Description

       polycrystalline dual glass solar panel / 330W / 72cells / 24V / white



Main Features

1. Outstanding module performance

Anti PID

High hot-spot resistance

Double semi-tempered glasses strengthen cracking resistance

Improve heat dissipation



2. Ensure fire safety performance

Replace polymer back plate with tempered glass, to improve fire safety performance

Passed fire safety test grade A



3. System cost reduction makes more efficiency

Maximum system voltage enhanced to 1500V

System overall cost reduced greatly, compared with 1000V system

30-year linear power warranty, only 0.5% annual linear degradation



4. Harsh environment adaptation

High transmittance, anti reflection, self-cleaning coated glass

No aluminum alloy frame, no PID

Excellent performance on wind & sand resistance, salt mist resistance, ammonia corrosion resistance



Electrical performance parameters

polycrystalline dual glass solar panel / 330W / 72cells / 24V / white
Electrical performance parameters
STC (AM1.5, 1000W/m², cell temperature 25℃)
Model MDG330(W)
Maximum power (Pm/Wp) 330
Maximum power voltage (Vmp/V) 37.63
Maximum power current (Imp/A) 8.77
Open circuit voltage (Voc/V) 45.61
Short circuit current (Isc/A) 9.54
Module efficiency (%) 16.9



General performance parameters

Mechanical performance parameters
Cell Nos & array 72(6*12)
Diode Nos 3
Cells dimension(mm) 156.75*156.75 poly
Cable 4mm2/negative 150mm, positive 300mm
Module weight (kg) 28
Module dimension (L*W*H) (mm) 1968*992*6(junction box thickness 16mm)
Packing 30pcs/pallet, 22cartons/40HQ, 660pcs/40HQ
Quality parameters
Module working temperature range (℃) -40~+85
Power tolerance (W) 0~+5
Maximum system voltage (V Dc) 1500DC
System maximum protection current (A) 15
Normal operating cell temperature (NOCT) 45±2℃
Maximum wind loads/maximum snow loads (Pa) 2400/5400
Hot spot 100% hot spot free
Temperature coefficient (STC)
Temperature coefficient of Voc -0.31%/℃
Temperature coefficient of Isc 0.05%/℃
Temperature coefficient of Pm -0.41%/℃



Drawing(mm)

Rixin Polycrystalline PV Module dual glass solar panel / 330W / 72cells / 24V 0



Quality Warranty

10-year materials&workmanship warranty

30-year linear power warranty

Rixin Polycrystalline PV Module dual glass solar panel / 330W / 72cells / 24V 1Rixin Polycrystalline PV Module dual glass solar panel / 330W / 72cells / 24V 2

RFQ

Q1 : What about delivery time?

A : Samples:within 7 working days.

Goods : 7-15 working days usually.

Q2 : Can you provide OEM service?

A : Yes,we can.Including customized logo/customized packaging/Graphic customization.

Q3 : Do you test the goods before shipment ?

A : Yes,we have professional QC team to test all the goods before packing.And we will check the packing before shipment.

Q4 : What about the quality warranty?

A : 12-year material & workmanship warranty.

  1. year linear power warranty.

Q5: What is you payment terms?

A : We accept T/T bank transfer,L/C, Paypal, Western union and MonryGram.

Q6 :What is your products’ advantage?

A : First ,we own our brand and we have over 20 years produce experience.We have cooperation projects with governments and well-known companies and have won a good reputation.



Self-branded

Formed in 2001,has a total of 500 employees. It has two manufacturing bases, with area 180000㎡ and fully automatic production lines.

Industry Experience

Rixin Technology is a clean energy company as well as one of the China’s leading crystalline silicon solar power companies.

Competitive products

High efficiency Perc mono half-cut bifacial module, BIPV laminated double glass module, Perc mono/poly framed solar panel, solar power system etc, at present, Rixin Technology’s total installed capacity of solar projects exceeds 1GW.

Professional Team



Certificate standard

Have IEC61215, IEC61730, CE, ISO9001 ,ISO14001 certificates
