95W 36 Cells Custom Solar Panels Polycrystalline Efficient For Solar Pump
100PCS
MOQ
Negotiable
Price
95W 36 Cells Custom Solar Panels Polycrystalline Efficient For Solar Pump
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Wuhan, China
Brand Name: Rixin
Certification: TUV, CE, ISO9001, ISO14001, OHSAS18000
Model Number: MBF95
High Light:

custom solar cells

,

custom made solar panels

Payment & Shipping Terms
Packaging Details: cartons/wooden cases
Delivery Time: 15 working days
Payment Terms: T/T
Supply Ability: 500MW/year
Specifications
Power: 95W
Dimension: 920*670*35mm
Cells: 36cells
Life Span: 25 Years
Product Description

      polycrystalline framed solar panel / 95W / 36 cells / 12V


Polycrystalline or Monocrystalline silicon is a material consisting of thin wafers that are cut from a silicon crystal which has grown in several directions.

This advanced texturing process provides polycrystalline or moncrystalline solar panels with a higher power output than amorphous panels of the same dimensions, and makes them more cost and space-effective. These individual wafers are assembled into panels that are covered by durable, weatherproof tempered glass. Thanks to their efficiency and durability, these solar panels require virtually no maintenance once installed.


Main Features
1. Over 25-year lifespan.

2. Available for charging 12V/24V battery.

3. Module dimension could be customized.

4. Suitable for solar street light, solar garden light, solar pump etc., on-grid or off-grid system.


Performance parameters



Model MBF95
Dimension (L*W*H) mm 920*670*35
Weight (kg) 6.85
Cell dimension (mm) 156*93.60
Cell Nos 36 (4*9)
Glass 3.2mm low-iron tempered glass
Frame Anodized aluminum alloy
Mounting holes customized
Junction box protection level IP65
Cable length customized
Connector customized, MC4 compatible
Power tolerance ±5%
Maximum power (Pm/Wp) 95
Maximum power voltage (Vmp/V) 18.5
Maximum power current (Imp/A) 5.14
Open circuit voltage (Voc/V) 22.0
Short circuit current (Isc/A) 5.47



Drawing-sample(mm)
95W 36 Cells Custom Solar Panels Polycrystalline Efficient For Solar Pump 0

Quality Warranty
10-year materials&workmanship warranty
25-year linear power warranty

95W 36 Cells Custom Solar Panels Polycrystalline Efficient For Solar Pump 195W 36 Cells Custom Solar Panels Polycrystalline Efficient For Solar Pump 2
