30W 36 Cells Custom Solar Panels Polycrystalline For Solar Street Light
1PC
MOQ
Negotiable
Price
30W 36 Cells Custom Solar Panels Polycrystalline For Solar Street Light
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Wuhan, China
Brand Name: Rixin
Certification: TUV, CE, ISO9001, ISO14001, OHSAS18000
Model Number: MBF30
High Light:

custom solar cells

,

custom made solar panels

Payment & Shipping Terms
Packaging Details: cartons/wooden cases
Delivery Time: 15 working days
Payment Terms: T/T
Supply Ability: 500MW/year
Specifications
Power: 30W
Dimension: 630*354*25mm
Cells: 36cells
Life Span: 25 Years
Product Description

      polycrystalline framed solar panel / 30W / 36cells / 12V


Performance parameters



Model MBF30
Dimension (L*W*H) mm 630*354*25
Weight (kg) 2.59
Cell dimension (mm) 78*62.4
Cell Nos 36 (4*9)
Glass 3.2mm low-iron tempered glass
Frame Anodized aluminum alloy
Mounting holes customized
Junction box protection level IP65
Cable length customized
Connector customized, MC4 compatible
Power tolerance ±5%
Maximum power (Pm/Wp) 30
Maximum power voltage (Vmp/V) 18.5
Maximum power current (Imp/A) 1.62
Open circuit voltage (Voc/V) 22.0
Short circuit current (Isc/A) 1.73



Drawing-sample(mm)
30W 36 Cells Custom Solar Panels Polycrystalline For Solar Street Light 0

Main Features
1. Over 25-year lifespan.

2. Available for charging 12V/24V battery.

3. Module dimension could be customized.

4. Suitable for solar street light, solar garden light, solar pump etc., on-grid or off-grid system.


Quality Warranty
10-year materials&workmanship warranty
25-year linear power warranty



30W 36 Cells Custom Solar Panels Polycrystalline For Solar Street Light 130W 36 Cells Custom Solar Panels Polycrystalline For Solar Street Light 2
