Polycrystalline Framed Custom Flexible Solar Panels 60W / 36 Cells / 12V

China Wuhan Rixin Technology Co., Ltd. certification
China Wuhan Rixin Technology Co., Ltd. certification
I'm Online Chat Now

Polycrystalline Framed Custom Flexible Solar Panels 60W / 36 Cells / 12V

Polycrystalline Framed Custom Flexible Solar Panels 60W / 36 Cells / 12V
Polycrystalline Framed Custom Flexible Solar Panels 60W / 36 Cells / 12V Polycrystalline Framed Custom Flexible Solar Panels 60W / 36 Cells / 12V Polycrystalline Framed Custom Flexible Solar Panels 60W / 36 Cells / 12V

Large Image :  Polycrystalline Framed Custom Flexible Solar Panels 60W / 36 Cells / 12V

Product Details:
Place of Origin: Wuhan, China
Brand Name: Rixin
Certification: TUV, CE, ISO9001, ISO14001, OHSAS18000
Model Number: MBF60
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: Negotiable
Packaging Details: cartons/wooden cases
Delivery Time: 15 working days
Payment Terms: T/T
Supply Ability: 500MW/year
Detailed Product Description
Power: 60W Dimension: 635*670*35mm
Cells: 36cells Life Span: 25 Years
High Light:

custom size solar cells

,

custom made solar panels

      polycrystalline framed solar panel / 60W / 36cells / 12V

Main Features



Solar Cell
* Anti PID
* High Efficiency PV Cells
* Appearance Consistency
* Color sorting ensure consistent appearance on each module



* Conventional frame
* Seal-lip design glue injection
* Silver or black frames are optional
* Serrated-clip design tensile strength
* Boost bearing capability and prolong service life


Performance parameters



Model MBF60
Dimension (L*W*H) mm 635*670*35
Weight (kg) 4.88
Cell dimension (mm) 156*62.4
Cell Nos 36 (4*9)
Glass 3.2mm low-iron tempered glass
Frame Anodized aluminum alloy
Mounting holes customized
Junction box protection level IP65
Cable length customized
Connector customized, MC4 compatible
Power tolerance ±5%
Maximum power (Pm/Wp) 60
Maximum power voltage (Vmp/V) 18.5
Maximum power current (Imp/A) 3.24
Open circuit voltage (Voc/V) 22.0
Short circuit current (Isc/A) 3.45



Drawing-sample(mm)
Polycrystalline Framed Custom Flexible Solar Panels 60W / 36 Cells / 12V 0

Quality Warranty
10-year materials&workmanship warranty
25-year linear power warranty

Polycrystalline Framed Custom Flexible Solar Panels 60W / 36 Cells / 12V 1Polycrystalline Framed Custom Flexible Solar Panels 60W / 36 Cells / 12V 2
