Aluminum Frame Custom Solar Cells , 105W 36 Cells Polycrystalline Solar Module

China Wuhan Rixin Technology Co., Ltd. certification
China Wuhan Rixin Technology Co., Ltd. certification
I'm Online Chat Now

Aluminum Frame Custom Solar Cells , 105W 36 Cells Polycrystalline Solar Module

Aluminum Frame Custom Solar Cells , 105W 36 Cells Polycrystalline Solar Module
Aluminum Frame Custom Solar Cells , 105W 36 Cells Polycrystalline Solar Module Aluminum Frame Custom Solar Cells , 105W 36 Cells Polycrystalline Solar Module Aluminum Frame Custom Solar Cells , 105W 36 Cells Polycrystalline Solar Module

Large Image :  Aluminum Frame Custom Solar Cells , 105W 36 Cells Polycrystalline Solar Module

Product Details:
Place of Origin: Wuhan, China
Brand Name: Rixin
Certification: TUV, CE, ISO9001, ISO14001, OHSAS18000
Model Number: MBF105
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: Negotiable
Packaging Details: cartons/wooden cases
Delivery Time: 15 working days
Payment Terms: T/T
Supply Ability: 500MW/year
Detailed Product Description
Power: 105W Dimension: 1010*670*35mm
Cells: 36cells Life Span: 25 Years
High Light:

custom size solar cells

,

custom solar cells

      polycrystalline framed solar panel / 105W / 36 cells / 12V

Main Features
1. Over 25-year lifespan.

2. Available for charging 12V/24V battery.

3. Module dimension could be customized.

4. Suitable for solar street light, solar garden light, solar pump etc., on-grid or off-grid system.





Frame

* Aluminium extrusion profile with prompt delivery

* Available in customized surface finish
* Excellent material for smooth and subtle edges
* Extrusion for construction and other industrial purposes
* Thickness variable according special request


Performance parameters



Model MBF105
Dimension (L*W*H) mm 1010*670*35
Weight (kg) 7.51
Cell dimension (mm) 156*104
Cell Nos 36 (4*9)
Glass 3.2mm low-iron tempered glass
Frame Anodized aluminum alloy
Mounting holes customized
Junction box protection level IP65
Cable length customized
Connector customized, MC4 compatible
Power tolerance ±5%
Maximum power (Pm/Wp) 105
Maximum power voltage (Vmp/V) 18.5
Maximum power current (Imp/A) 5.68
Open circuit voltage (Voc/V) 22.0
Short circuit current (Isc/A) 6.04



Drawing-sample(mm)
Aluminum Frame Custom Solar Cells , 105W 36 Cells Polycrystalline Solar Module 0

Quality Warranty
10-year materials&workmanship warranty
25-year linear power warranty



Aluminum Frame Custom Solar Cells , 105W 36 Cells Polycrystalline Solar Module 1Aluminum Frame Custom Solar Cells , 105W 36 Cells Polycrystalline Solar Module 2Aluminum Frame Custom Solar Cells , 105W 36 Cells Polycrystalline Solar Module 3
