Rixin 550w Double Glass PV Modules Monocrystalline Silicon Solar Panel Price
100000watt
MOQ
negotiations
Price
Rixin 550w Double Glass PV Modules Monocrystalline Silicon Solar Panel Price
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: Rixin
Certification: CE\Rohs\CCC\ISO9001
Model Number: DDG(P)540(K)
High Light:

545w High Power Solar Panels

,

540w High Power Solar Panels

,

540w Monocrystalline Silicon PV Modules

Payment & Shipping Terms
Packaging Details: Safety standard installation
Delivery Time: 7 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,payapl
Supply Ability: 1000000000watt/week
Specifications
Name: 540w Solar Panel
Maximum Power(Pm/Wp): 540v
Maximum Power Voltage(Vmp/V): 42.09
Maximum Power Current(lmp/V): 12.83
Module Efficient(%): 20.83
Cell Nos & Array: Mono Half-cut Cells 144 Pcs
Feature: With Frame
Cell Size (mm): 182*91
Frame: Anodized Alaminum Alloy
Material: Monocrystalline Silicon
Warranty: 25 Years Output Power Guarantee
Junction Box: IP67 Rated
Max. Power: 550W
Number Of Cells: 144pcs
Type: Double Glass Solar Panel
Application: Commercial,Solar Power System,Street Light,Industrial
Oem Order: Accept Customized
Front Glass: High Transparency Glass
Product Description

Rixin 550w Double Glass PV Modules Monocrystalline Silicon Solar Panel Price



Main Features

1. High power output

30 year linear performance warranty, more than 30% additional power gain.



2. Zero LID & PID

No LID, more power generation.

No PID, stable power generation.



3. Fire safety performance

Higher fire safety class to minimize fire risks.



4. Outstanding module performance

Higher power output, even under low light conditions.

Excellent low irradiation performance and below -0.38% /℃ temperature coefficient of Power.



5. Wider applications & more flexible installed angle

No water-permeability and high wear-resistance, can be widely used in high-humid, strong wind&sand areas and not limited to traditional slope installation.

25 Years Solar Panel Warranty





Self-branded

Formed in 2001,has a total of 500 employees. It has two manufacturing bases, with area 180000㎡ and fully automatic production lines.

Industry Experience

Rixin Technology is a clean energy company as well as one of the China’s leading crystalline silicon solar power companies.

Competitive products

High efficiency Perc mono half-cut bifacial module, BIPV laminated double glass module, Perc mono/poly framed solar panel, solar power system etc, at present, Rixin Technology’s total installed capacity of solar projects exceeds 1GW.

Professional Team



Certificate standard

Have IEC61215, IEC61730, CE, ISO9001 ,ISO14001 certificates



Rixin 550w Double Glass PV Modules Monocrystalline Silicon Solar Panel Price 0

Rixin 550w Double Glass PV Modules Monocrystalline Silicon Solar Panel Price 1Rixin 550w Double Glass PV Modules Monocrystalline Silicon Solar Panel Price 2

Mono Bifacial Double Glass Module DDG(P)530-550(k)

Model DDG(P)530(k) DDG(P)535(k) DDG(P)540(k) DDG(P)545(k) DDG(P)550(k)
Maximum power(Pm/Wp) 530 535 540 545 550
Maximum power voltage(Vmp/V) 41.64 41.87 42.09 42.32 42.54
Maximum power current(lmp/V) 12.73 12.78 12.83 12.88 12.93
Open circuit voltage(Voc/V) 49.65 49.78 49.91 50.12 50.34
Short circuit current(Isc/A) 13.48 13.53 13.58 13.63 13.68
Module efficient(%) 20.45 20.64 20.83 21.03 21.22

Test condition:irradiance=(1+0.1BiFi)1000W/㎡,ambient temperature=25℃,AM=1.5

Rixin 550w Double Glass PV Modules Monocrystalline Silicon Solar Panel Price 3

Mechanical performance parameters

Cell Nos & array Mono half-cut cells 144 pcs
Cell size (mm) 182*91
Glass thickness (mm) 2.0
Frame Anodized alaminum alloy
Cable 4m㎡ negetive300mm, positive300mm
Module weight (kg) 32.1
Module dimension (L*W*H)(mm) 2285*1134*35mm
Packing 31pcs/pallet



Quality parameters

Module working temperature range (℃) -40~ +85
Power tolerance(W) 0~+5
Maximum system voltage(V) DC1500
System maximum protection current(A) 25
NOCT(℃) 45±2
Front/rear static loads(Pa) 2400 / 5400
Junction box/Connector Ip68,split / MC4 compatible



Temperaturecoefficient(STC)

Temperature coefficient of Voc -0.3%/℃
Temperature coefficient of Isc +0.06%/℃
Temperature coefficient of Pm -0.39%/℃
Test condition:irradiance=(1+0.1BiFi)1000W/㎡,ambient temperature=25℃,AM=1.5



Quality warranty

12-year material & workmanship warranty

30-year linear power warranty



Rixin 550w Double Glass PV Modules Monocrystalline Silicon Solar Panel Price 4

Rixin 550w Double Glass PV Modules Monocrystalline Silicon Solar Panel Price 5Rixin 550w Double Glass PV Modules Monocrystalline Silicon Solar Panel Price 6

Rixin Technology is a clean energy company as well as one of the China’s leading crystalline silicon solar power companies, committed to change the world by solar energy.

Formed in 2001, the company is headquartered in Wuhan.It has two manufacturing bases, with area 180000 square meters and fully automatic production lines. Through its rational investment and industrial, Rixin Technology has formed an entire chain including R&D of core technology, manufacturing, integration and service etc.

With core products covering high efficiency Perc mono half-cut bifacial module, BIPV laminated double glass module, Perc mono/poly framed solar panel, solar power system etc, at present, Rixin Technology’s total installed capacity of solar projects exceeds 1GW.

Rixin Technology believes that high efficiency crystalline modules will define the future of PV industry. Rixin Technology specializes in the development of high efficiency crystalline solar technical roadmap and it has become great PV companies in terms of its scale and the leading expertise in China.

We use top-quality solar cells and EVA, TPT, strengthen glass, seal silicone etc. Our experienced staffs work together well to assurance quality under effective ISO system, CE, to assure our quality Our products are exported to Europe, America and Asian countries with safety certificates.

Our value is coordination, innovation, sincerity, service. We will make unremitting efforts to be your great partner on your path of the photovoltaic wealth.



RFQ

Q1 : What about delivery time?

A : Samples:within 7 working days.

Goods : 7-15 working days usually.

Q2 : Can you provide OEM service?

A : Yes,we can.Including customized logo/customized packaging/Graphic customization.

Q3 : Do you test the goods before shipment ?

A : Yes,we have professional QC team to test all the goods before packing.And we will check the packing before shipment.

Q4 : What about the quality warranty?

A : 12-year material & workmanship warranty.

      30-year linear power warranty.

Q5: What is you payment terms?

A : We accept T/T bank transfer,L/C, Paypal, Western union and MonryGram.

Q6 :What is your products’ advantage?

A : First ,we own our brand and we have over 20 years produce experience.We have cooperation projects with governments and well-known companies and have won a good reputation.
