High Efficiency P Type Standard Solar Panel 325W Sound insulation and heat insulation
840PCS/HQ
MOQ
Negotiable
Price
High Efficiency P Type Standard Solar Panel 325W Sound insulation and heat insulation
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Wuhan, China
Brand Name: Rixin
Certification: TUV, CE, ISO9001, ISO14001, OHSAS18000
Model Number: DDM(N)325
High Light:

n type silicon solar cell

,

photovoltaic solar panels

Payment & Shipping Terms
Packaging Details: 33pcs/carton, 26cartons/40HQ, 858pcs/40HQ
Delivery Time: 15 working days
Payment Terms: T/T, L/C
Supply Ability: 3GW/YEAR
Specifications
Power: 325W
Dimension: 1658*992*6mm
Efficiency: 19.80%
Life Span: 30 Years
Product Name: Photovoltaic Solar Panels
Type: Mono Half-cut Cells
Application: Sun Rooms, Skylights, Carports, Sound Insulation Panels
Product Description

       N type monocrystalline bifacial dual glass solar panel / 325W / 60cells / 20V



The solar panel is made to our specifications , the systems are ideal for homeuse with fridge ,light, and other home applicance. clean energy is needed. They are very popular among the international market and will the future tender of new energy.



Main Features



1. High power output

30 year linear performance warranty, more than 30% additional power gain.



2. Zero LID & PID

No LID, more power generation.

No PID, stable power generation.



3. Fire safety performance

Higher fire safety class to minimize fire risks.



4. Outstanding module performance

Higher power output, even under low light conditions.

Excellent low irradiation performance and below -0.38% /℃ temperature coefficient of Power.



5. Wider applications & more flexible installed angle

No water-permeability and high wear-resistance, can be widely used in high-humid, strong wind&sand areas and not limited to traditional slope installation.



Efficiency
1. Low voltage-temperature coefficient allows higher solar power output at high-temperature condition.
2. High efficient, high reliable photovoltaic solar cells ensure our product output stability.
Best Quality Materials Making our High quality solar panels/solar energy/best solar /solar power system :
1. Solar cells------ Germany manufactured Bosch solar cell, efficiency is about 18%
2. Front glass------ high transmission, low iron, tempered glass.
3. EVA-----excellent anti-aging EVA
4. TPT------TPT hot seal made of flame resistance, imported.
5. Aluminum Frame----- Unique aluminium frame design with high mechanical strength for installation. .
6. Junction box----- Ip65 rated, high quality, with diode protection .



Electrical performance parameters

N type monocrystalline bifacial dual glass solar panel / 325W / 60cells / 20V
Electrical performance parameters
Test condition: irradiance=(1+0.1BiFi)1000W/m2, ambient temperature=25℃, AM=1.5
Model DDM(N)325
Maximum power (Pm/Wp) 325
Maximum power voltage (Vmp/V) 31.5
Maximum power current (Imp/A) 10.32
Open circuit voltage (Voc/V) 38.70
Short circuit current (Isc/A) 10.84
Module efficiency (%) 19.80
Electrical performance parameters (NOCT)
NOCT: irradiance=(1+0.1BiFi)800W/m2, ambient temperature=20℃, AM=1.5, wind speed=1m/s
Maximum power (Pm/Wp) 238
Maximum power voltage (Vmp/V) 28.90
Maximum power current (Imp/A) 8.24
Open circuit voltage (Voc/V) 35.80
Short circuit current (Isc/A) 8.67



General performance parameters

Mechanical performance parameters
Cell Nos & array 60 (6*10)
Diode Nos 3
Junction box IP68, split
Cable 4mm2, 300mm, length custom
Weight(kg) 23
Dimension (L*W*H) (mm) 1658*992*6 (junction box thickness 23mm)
Packing 33pcs/carton, 26cartons/40HQ, 858pcs/40HQ
Temperature coefficient (STC)
Temperature coefficient of Voc -0.300%/℃
Temperature coefficient of Isc +0.048%/℃
Temperature coefficient of Pm -0.380%/℃
Quality parameters
Working temperature range (℃) -40~+85
Power tolerance (W) 0~+5
Maximum system voltage (V) DC1500
System maximum protection current (A) 15
NOCT(℃) 45±2℃
Front/rear static loads(Pa) 5400/2400
Bifacial factor ≥85%
Hot spot 100% hot spot free


Drawing(mm)



High Efficiency P Type Standard Solar Panel 325W Sound insulation and heat insulation 0

Quality Warranty

10-year materials&workmanship warranty

30-year linear power warranty

High Efficiency P Type Standard Solar Panel 325W Sound insulation and heat insulation 1High Efficiency P Type Standard Solar Panel 325W Sound insulation and heat insulation 2
