All Black Standard Solar Panel with Ip68 junction , 325W Solar Photovoltaic Cell Monocrystalline
1PC
MOQ
Negotiable
Price
All Black Standard Solar Panel with Ip68 junction , 325W Solar Photovoltaic Cell Monocrystalline
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Wuhan, China
Brand Name: Rixin
Certification: TUV, CE, ISO9001, ISO14001, OHSAS18000
Model Number: DDP325(K)
High Light:

n type solar cell

,

n type silicon solar cell

Payment & Shipping Terms
Packaging Details: 33pcs/carton, 26cartons/40HQ, 858pcs/40HQ
Delivery Time: 15 working days
Payment Terms: T/T
Supply Ability: 500MW/year
Specifications
Power: 325W
Dimension: 1658*992*6mm
Module Efficiency: 19.80%
Life Span: 30 Years
Appearance Color: Black
Type: Mono Half-cut Cells
Junction Box/Connector: Ip68,split / MC4 Compatible
Cell Nos & Array: Mono Half-cut Cells 108 (6*9*2)
Product Description

All Black Standard Solar Panel with Ip68 junction , 325W Solar Photovoltaic Cell Monocrystalline



The solar panel is made to our specifications , the systems are ideal for homeuse with fridge ,light, and other home applicance. clean energy is needed. They are very popular among the international market and will the future tender of new energy.

Outstanding module performance



Anti PID



High hot-spot resistance



Double semi-tempered glasses strengthen cracking resistance



Improve heat dissipation



Ensure fire safety performance



Replace polymer back plate with tempered glass, to improve fire safety perormance



Passed fire safety test grade A



System cost reduction makes more efficiency



Maximum system voltage enhanced to 1500V



Compared with 1000V system, system overall cost reduced greatly



30-year linear power warranty, only 0.5% annual linear degradation



Harsh environment adaptation



High transmittance,anti reflection, self-cleaning coated glass

No aluminum alloy frame, no grounding

Excellent performance on wind & sand resistance, salt mist resistance, ammonia corrosion resistance

Passsed positive snow loads(5400pa) and wind loads(2400pa) certification tests.

All Black Standard Solar Panel with Ip68 junction , 325W Solar Photovoltaic Cell Monocrystalline 0



Model DDP315(K) DDP320(K) DDP325(K)
Maximum power(Pm/Wp) 315 320 325
Maximum power voltage(Vmp/V) 29.3 29.4 29.5
Maximum power current(lmp/V) 10.75 10.88 11.00
Open circuit voltage(Voc/V) 35.9 36 36.1
Short circuit current(Isc/A) 11.54 11.60 11.66
Module efficient(%) 19.0 19.3 19.6

Test condition:irradiance=(1+0.1BiFi)1000W/㎡,ambient temperature=25℃,AM=1.5



Mechanical performance parameters

Cell Nos & array Mono half-cut cells 108 (6*9*2)
Appearance color Black
Cable 4m㎡ negetive1000mm,positive1000mm
Module weight (kg) 19
Module dimension (L*W*H)(mm) 1600*1036*5mm
Packing 33pcs/pallet
Power optimizer matching form 2 modules equipped with 1 optimizer



Quality parameters

Module working temperature range (℃) -40~ +85
Power tolerance(W) 0~+5
Maximum system voltage(V) DC1500
System maximum protection current(A) 20
NOCT(℃) 45±2
Front/rear static loads(Pa) 2400 /2400
Junction box/Connector Ip68,split / MC4 compatible



Temperaturecoefficient(STC)

Temperature coefficient of Voc -0.3%/℃
Temperature coefficient of Isc +0.06%/℃
Temperature coefficient of Pm -0.39%/℃
Test condition:irradiance=(1+0.1BiFi)1000W/㎡,ambient temperature=25℃,AM=1.5



Quality warranty

12-year material & workmanship warranty

30-year linear power warranty





All Black Standard Solar Panel with Ip68 junction , 325W Solar Photovoltaic Cell Monocrystalline 1

RFQ

Q1 : What about delivery time?

A : Goods : 10-15 working days usually.

Q2 : Can you provide OEM service?

A : Yes,we can.Including customized logo/customized packaging/Graphic customization.

Q3 : Do you test the goods before shipment ?

A : Yes,we have professional QC team to test all the goods before packing.And we will check the packing before shipment.

Q4 : What about the quality warranty?

A : 12-year material & workmanship warranty.

  1. year linear power warranty.

Q5: What is you payment terms?

A : We accept T/T bank transfer,L/C, Paypal, Western union and MonryGram.

Q6 :What is your products’ advantage?

A : First ,we own our brand and we have over 20 years produce experience.We have cooperation projects with governments and well-known companies and have won a good reputation.



Self-branded

Formed in 2001,has a total of 500 employees. It has two manufacturing bases, with area 180000㎡ and fully automatic production lines.

Industry Experience

Rixin Technology is a clean energy company as well as one of the China’s leading crystalline silicon solar power companies.

Competitive products

High efficiency Perc mono half-cut bifacial module, BIPV laminated double glass module, Perc mono/poly framed solar panel, solar power system etc, at present, Rixin Technology’s total installed capacity of solar projects exceeds 1GW.

Professional Team

Professional saling service and after-sale service.

R&D staff is over 10% employees.

Perfect logistics and warehousing services.
