Monocrystalline Bifacial Standard Solar Panel 325W / 60 Cells / 20V High Power Output
100PC
MOQ
Negotiable
Price
Monocrystalline Bifacial Standard Solar Panel 325W / 60 Cells / 20V High Power Output
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Wuhan, China
Brand Name: Rixin
Certification: TUV, CE, ISO9001, ISO14001, OHSAS18000
Model Number: DDM(N)325
High Light:

n type silicon solar cell

,

photovoltaic solar panels

,

Bifacial Standard Solar Panel 325W

Payment & Shipping Terms
Packaging Details: 33pcs/carton, 26cartons/40HQ, 858pcs/40HQ
Delivery Time: 15 working days
Payment Terms: T/T
Supply Ability: 500MW/year
Specifications
Power: 325W
Dimension: 1658*992*6mm
Efficiency: 19.80%
Life Span: 30 Years
Type: Photovoltaic Solar Aluminum Carport N/W Type
Junction Box: TUV Certificate IP67 Waterproof
Warranty: 25 Years Output Power Guarantee
Number Of Cells: 72pcs Or Customized
Product Name: Photovoltaic Solar Panels
Application: Roofing System,Home Solar System
Front Glass: High Transmission,High Transparency Temperd Glass
Oem Order: Acceptable,Customnized Solar Panel
Advantage: High Efficiency,Easy Installing And Adjustable,Durability
Product Description



       Monocrystalline Bifacial Standard Solar Panel 325W / 60 Cells / 20V High Power Output



The solar panel is made to our specifications , the systems are ideal for homeuse with fridge ,light, and other home applicance. clean energy is needed. They are very popular among the international market and will the future tender of new energy.





Electrical performance parameters

N type monocrystalline bifacial dual glass solar panel / 325W / 60cells / 20V
Electrical performance parameters
Test condition: irradiance=(1+0.1BiFi)1000W/m2, ambient temperature=25℃, AM=1.5
Model DDM(N)325
Maximum power (Pm/Wp) 325
Maximum power voltage (Vmp/V) 31.5
Maximum power current (Imp/A) 10.32
Open circuit voltage (Voc/V) 38.70
Short circuit current (Isc/A) 10.84
Module efficiency (%) 19.80
Electrical performance parameters (NOCT)
NOCT: irradiance=(1+0.1BiFi)800W/m2, ambient temperature=20℃, AM=1.5, wind speed=1m/s
Maximum power (Pm/Wp) 238
Maximum power voltage (Vmp/V) 28.90
Maximum power current (Imp/A) 8.24
Open circuit voltage (Voc/V) 35.80
Short circuit current (Isc/A) 8.67



General performance parameters

Mechanical performance parameters
Cell Nos & array 60 (6*10)
Diode Nos 3
Junction box IP68, split
Cable 4mm2, 300mm, length custom
Weight(kg) 23
Dimension (L*W*H) (mm) 1658*992*6 (junction box thickness 23mm)
Packing 33pcs/carton, 26cartons/40HQ, 858pcs/40HQ
Temperature coefficient (STC)
Temperature coefficient of Voc -0.300%/℃
Temperature coefficient of Isc +0.048%/℃
Temperature coefficient of Pm -0.380%/℃
Quality parameters
Working temperature range (℃) -40~+85
Power tolerance (W) 0~+5
Maximum system voltage (V) DC1500
System maximum protection current (A) 15
NOCT(℃) 45±2℃
Front/rear static loads(Pa) 5400/2400
Bifacial factor ≥85%
Hot spot 100% hot spot free



Main Features

1. High power output

30 year linear performance warranty, more than 30% additional power gain.



2. Zero LID & PID

No LID, more power generation.

No PID, stable power generation.



3. Fire safety performance

Higher fire safety class to minimize fire risks.



4. Outstanding module performance

Higher power output, even under low light conditions.

Excellent low irradiation performance and below -0.38% /℃ temperature coefficient of Power.



5. Wider applications & more flexible installed angle

No water-permeability and high wear-resistance, can be widely used in high-humid, strong wind&sand areas and not limited to traditional slope installation.



Drawing(mm)



Monocrystalline Bifacial Standard Solar Panel 325W / 60 Cells / 20V High Power Output 0

Quality Warranty

10-year materials&workmanship warranty

30-year linear power warranty

Monocrystalline Bifacial Standard Solar Panel 325W / 60 Cells / 20V High Power Output 1Monocrystalline Bifacial Standard Solar Panel 325W / 60 Cells / 20V High Power Output 2
