Bifacial Monocrystalline Double Glass Solar Panel 300 Watt 30 Years Life Span

China Wuhan Rixin Technology Co., Ltd. certification
China Wuhan Rixin Technology Co., Ltd. certification
I'm Online Chat Now

Bifacial Monocrystalline Double Glass Solar Panel 300 Watt 30 Years Life Span

Bifacial Monocrystalline Double Glass Solar Panel 300 Watt 30 Years Life Span
Bifacial Monocrystalline Double Glass Solar Panel 300 Watt 30 Years Life Span Bifacial Monocrystalline Double Glass Solar Panel 300 Watt 30 Years Life Span

Large Image :  Bifacial Monocrystalline Double Glass Solar Panel 300 Watt 30 Years Life Span

Product Details:
Place of Origin: Wuhan, China
Brand Name: Rixin
Certification: TUV, CE, ISO9001, ISO14001, OHSAS18000
Model Number: DDM(P)300
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: Negotiable
Packaging Details: 33pcs/carton, 26cartons/40HQ, 858pcs/40HQ
Delivery Time: 15 working days
Payment Terms: T/T
Supply Ability: 500MW/year
Detailed Product Description
Front Power: 300W Dimension: 1658*992*6mm
Front Efficiency: 18.2% Life Span: 30 Years
High Light:

perc solar panels

,

bifacial solar panels



  Perc Bifacial monocrystalline double glass solar panels , 300 watt solar panel



Main Features

1. High module conversion efficiency.

2. Better energy yield with excellent low irradiance performance and temperature coefficient.

3. First year power degradation <2%.

4. Bifacial technology enables additional energy harvesting from rear side.

5. Glass/glass ensures 30 year product life span, with annual power degradation <0.45%.

6. Frameless design, no PID.



Electrical performance parameters(front side)

Electrical performance parameters(front side)
STC(Standard Testing Conditions) (irradiance 1000W/m2, cell temperature 25℃, spectra at AM1.5)
Model DDM(P)300
Maximum power (Pm/Wp) 300
Maximum power voltage (Vmp/V) 32.9
Maximum power current (Imp/A) 9.11
Open circuit voltage (Voc/V) 39.6
Short circuit current (Isc/A) 9.58
Module efficiency (%) 18.2




Electrical performance parameters(rear side)

Electrical performance parameters(rear side)
Model DDM(P)300
Maximum power (Pm/Wp) 226
Maximum power voltage (Vmp/V) 33.7
Maximum power current (Imp/A) 6.71
Open circuit voltage (Voc/V) 39.3
Short circuit current (Isc/A) 7.33
Module Efficiency (%) 13.7




General performance parameters

Mechanical performance parameters
Cell Nos & array 60(6*10)
Diode Nos 3
Junction box IP68, split
Cable 4mm2, 300mm, length custom
Module weight(kg) 23
Dimension (L*W*H) (mm) 1658*992*6 (junction box thickness 23mm)
Packing 33pcs/carton, 26cartons/40HQ, 858pcs/40HQ
Temperature coefficient (STC)
Temperature coefficient of Voc -0.290%/℃
Temperature coefficient of Isc +0.050%/℃
Temperature coefficient of Pm -0.390%/℃
Quality parameters
Working temperature range (℃) -40~+85
Power tolerance (W) 0~+5
Maximum system voltage (V) DC1500
System maximum protection current (A) 20
NOCT(℃) 45±2℃
Front/rear static loads(Pa) 5400/2400
Bifacial factor ≥75%
Hot spot 100% hot spot free



Drawing(mm)

Bifacial Monocrystalline Double Glass Solar Panel 300 Watt 30 Years Life Span 0



Quality Warranty

10-year materials&workmanship warranty

30-year linear power warranty

Bifacial Monocrystalline Double Glass Solar Panel 300 Watt 30 Years Life Span 1Bifacial Monocrystalline Double Glass Solar Panel 300 Watt 30 Years Life Span 2
